35
10.4.2 Polarities (P1: one character)
P1 Code Description
+ 2BH When data is zero or positive
- 2DH When data is negative
(SP) 20H When data is zero or positive
10.4.3 Numeric data
Six-digit numeric format: (D1–D7: seven characters)
Seven-digit numeric format: (D1–D8: eight characters)
D1–D7 (D8) Code Description
0–9 30H–39H Numerical value 0–9
•
2EH
Decimal point (floating position)
※When the data is an integer, it may be omitted and
replaced with a blank space (SP) in the lowest-order place.
(SP) 20H
Space: zero of leading portion of value (leading zero
suppress)
10.4.4 Units (U1, U2: two characters)
※ All the codes are ASCII codes.
U1 U2 Code Meaning Balance indicators
(SP) G 20H 47H Gram
g
C T 43H 54H Carat
O Z 4FH 5AH Ounce
L B 4CH 42H Pound
O T 4FH 54H troy ounce
D W 44H 57H Pennyweight
G R 47H 52H Grain
 (lower right)
T L 54H 4CH tael (Hong Kong)
T L 54H 4CH tael (Singapore, Malaysia)  (upper right)
T L 54H 4CH tael (Taiwan)
 (lower right)
M O 4DH 4FH Momme
Mom
t o 74H 6FH Tola
(SP) % 20H 25H Percentage
%
P C 50H 43H Pieces
Pcs
