32
Preparation at the field
Placing into working
position
Machine without hydrau-
lic cylinder
Before use, the machine must be fully swung beside the tractor.
> Unlock and fold down the lateral guard
> Place the lower lock in working position
> Place the upper lock in working position
Machine without hydraulic safety breakaway
From the tractor seat:
> Use the 3-point hitch to lower the machine just from the ground
> Pull the rope fully and hold it
> Use the 3-point hitch to lower the machine just at the ground
> Drive backwards and steer to the left to swing the machine into
working position beside the tractor
> Release the rope and ensure it is locked
> Use the 3-point hitch to lift the machine to the desired working
height
Machine with hydraulic safety breakaway
> Open the valve at the hydraulic safety breakaway
From the tractor seat:
> Use the 3-point hitch to lift the machine to the desired working
height
> Use the hydraulic safety breakaway cylinder to swing the machine
into working position beside the tractor
Lower lockWorking
position
Upper lock
