Preparation at the field
33
Machine with hydraulic
cylinder
Before use, the machine must be fully swung and lowered (if neces-
sary) beside the tractor.
> Unlock and fold down the lateral guard
> Place the lower lock in working position
> Place the upper lock in working position
> Open the valve at the hydraulic cylinder
Machine without hydraulic safety breakaway
From the tractor seat:
> Lower the mowing unit horizontally using the hydraulic cylinder
> Pull the rope fully and hold it
> Use the 3-point hitch to lower the machine just at the ground
> Drive backwards and steer to the left to swing the machine into
working position behind the tractor
> Release the rope and ensure it is locked
> Use the 3-point hitch to lift the machine to the desired working
height
Lower lockWorking
position
Upper lock
