Videojet 6210 Operator Manual
6-2 Technical Specifications
Rev AB
Dimensions
Printhead (including cassette) 167 mm (W) x 158 mm (H) x
160 mm (D) (6.6 inches x 6.2
inches x 6.3 inches)
Controller/User interface 119 mm (W) x 208 mm (H) x
97 mm (D)
(4.7 inches x 8.2 inches x 3.8
inches)
Inputs/Outputs
External Inputs 2 PNP inputs
Print sensor 1
Inhibit print
External Outputs 2 relay outputs (1 change-
over + 1 N/O) and 2 PNP +24
V outputs (max source cur-
rent = 100 mA per output)
Warning
Busy
Printing/Spare (actually ener-
gising print dots)
Fault
Operator Interface (CLARiTY) 5.7 inches CSTN QVGA
Power supply requirements 100 -240 VAC, 50/60Hz,
0.95-1.8 A, single-phase type
‘TN’ or ‘TT’ 320 VA (max),
2.75 A@115 V AC, 1.4A @
230 V AC, 60 A max surge @
230 V, 30 A max surge@115
V
Air supply requirements 6 bar (90 psi)
uncontaminated, 1.0 ml/cycle
(max)
Operating Temperature 10° C - 40° C (50° - 104° F)
Approvals
1
CE//NRTL Approval (by MET-
LAB) to UL60950
1. Further information available on request.
Technical Specification
Videojet 6210
Table 6-1: Technical Specifications (Continued)
