Rev AB Technical Specifications 6-1
6
Specifications
This chapter contains the following topics:
• Technical specifications
• System specifications
• Print specifications
• Networking and external communications
• Printer dimensions Videojet 6210
Technical Specifications
Table 6-1 lists the technical specifications of the printer.
Technical Specification
Videojet 6210
Printer
Unique SolidState Ribbon Drive Intermittent Motion and Con-
tinuous Motion
Printhead 35 mm (1.4 inches), 300 dpi,
12 dots/mm
Print Area - Intermittent Motion
Mode
32 mm (W) x 30 mm (L) (1.26
inches x 1.18 inches)
Print Area - Continuous Motion
Mode
32 mm (W) x 30 mm (L) (1.26
inches x 1.18 inches)
Ribbon Width 20 mm - 35 mm (0.8 inches -
1.39 inches)
Maximum
Ribbon Length
600 metres (1968 feet)
Intermittent Motion Mode 50 mm/sec - 200 mm/sec (1.9
inches/sec - 7.9 inches/sec)
#1
Print Speed
Continuous Motion Mode 40 mm/sec - 500 mm/sec (1.6
inches/sec - 19.7 inches/sec)
#1
Table 6-1: Technical Specifications
