PAGE 24 of 36 VR GSM DOOR INTERCOM TECHNICAL MANUAL VER2.0.0
PROGRAMMING BY DIAL IN
Note: programming dial in cannot be used from telephones which are already
programmed to open the door when they dial the intercom panel.
When dialling into the GSM intercom from a telephone number which is already
stored as one of the call button telephone numbers it will be necessary be press
to switch from call mode to programming mode.
To gain access to the programming menu via dial in, follows these steps:-
1. Call the telephone number of the intercom panel.
2. Wait for the intercom panel to answer and signal by two beeps (If the number you
are dialling from is already programmed as a call button number then you will need
to press before proceeding to the next step).
3. Enter the four digit code listening for a confirmation beep after each digit.
4. If the code is correct, you will here two beeps to indicate programming mode. If the
code is incorrect the call will end and the line will go dead.
Once in programming mode, the following options are available. Remember to listen for a
beep after each digit entered. This indicates that it has been received and understood by
the intercom panel. The intercom panel will stay in programming mode until the call ends
or a timeout occurs. The timeout will occur after 30 seconds if no buttons are pressed. This
is reset to 30 seconds each time a button is pressed.
Note: At any point press the # key to clear and begin a programming sequence again. # is
also used to confirm and store a new value. After pressing #, two beeps will be heard from
the telephone to indicate successful completion of a command, four beeps will indicate an
error in the command.
The following table outlines the available programming codes. These are explained in detail on the following pages.
DESCRIPTION CODE EXAMPLE SETTINGS DEFAULT PAGE
Store a telephone no. 01-10 nn01912243174# nn = 01-10 N/A 26
Storing a divert telephone no. 11-29 nn01912243174# nn = 11-20 N/A 26
Set call duration time 50 50nn# nn = 01-12 02 26
Set relay time 51 51nn# nn = 00 - 99 05 (5s) 26
Set auxiliary out time 52 52nn# nn = 00 - 99 05 (5s) 26
Keep connection facility 55 55nn# nn = 01 - 99 10 (10days) 27
Divert to second no. time 56 56nn# nn = 01 - 99 15 (15s) 27
Set auxiliary out mode 57 57nn# nn = 01 or 00 01 27
Enable/disable divert 58 58nm# n = 0-9 m = 0-1 m = 0 27
Change 4 digit code 59 59nnnn# nnnn= 4 digits 1111 26
NOTE: While in dial in mode it is also possible to start a call with the intercom panel
which will open the speech and also allow the user functions such as
triggering the relay to work. After dialling in, enter the 4 digit code and the
press to start the call.
