116
6167 818 - 10
Vitodens 100-W, B1HE/B1KE Combi Installation/Service
Parts
Parts List
(continued)
Boiler Model No. Serial No.
B1HE-85 7722772
B1HE-120 7722773
Ordering Parts:
Please provide Serial Number when ordering
replacement parts. Order replacement
components from your Viessmann distributor.
Pump Module
0001 Round seal ring (5 pcs)
0002 O-Rings (5 pcs)
0003 Screw (5 pcs)
0004 Valve insert
0005 O-Ring (5 pcs)
0006 Connector G3/4
0007 Fuse clip nipple connection
0008 Compact carrier sheet hydraulics
0009 Circulation adapter
0010 Circulation adapter return flow side
0011 Clip D=24 (5 pcs)
0012 Screw EJOT (5 pcs)
0013 Plug D=8/D=10
0014 Clip D=8 small (5pcs)
0015 Return flow housing with cap and plug
0016 Circulation pump motor 115V
0017 Flow housing
0018 Flow switch
0019 Gasket set
To Next Page
