48
Ideal angle of penetration
C
A
B
Fig. 31
A
WiFi router
B
Heat generator
C
Wall
Minimum clearances
Secondary circuit connections, left/top
1000
250
Fig. 32
Secondary circuit connections, right/top
1000
250
Fig. 33
Installing the indoor unit
Requirements for the installation room (cont.)
6222080
Installation
