Viessmann VITOCAL 350 - Specification (cont.); Vitocal 350 Water;Water (Single Stage)

Vitocal 350 water/water heat pump (single stage)
Vitocal 350 (single stage) Type WWH 110 WWH 113
Output data
At operating point
*
1
W10/W35 W8/W55 W8/W65 W10/W35 W8/W55 W8/W65
Rated heating output kW 14.1 14.6 14.6 19.7 19.4 19.4
Refrigerating capacity kW 11.40 10.30 9.45 15.90 13.65 12.15
Power consumption kW 2.70 4.30 5.15 3.80 5.75 7.25
Coefficient of Performance ∊ (COP) 5.22 3.39 2.83 5.18 3.37 2.68
Groundwater (primary)
Content litre 3.7 4.7
Min. throughput
*
2
l/h 2700 3800
Pressure drop mbar 90 100
Max. inlet temperature °C 20 20
Min. inlet temperature
– for min. throughput °C 7.5 7.5
– for min. throughput +40 °C 6.5 6.5
Heating water (secondary)
Content litre 3.3 3.3
Min. throughput
*
2
l/h 1060 1430
Pressure drop mbar 40 45
Max. flow temperature °C 65 65
Electrical values
Heat pump
Rated voltage 3/N/PE 400 V/50 Hz
Rated current (max.) A 9.1 14.0
Starting current A 23
*
3
26
*
3
Starting current A 59.5 70.5
(with stalled armature)
Fuse(slow) A 3×20 3×20
Protection IP 20
Control circuit rated voltage 230 V/50 Hz
Fuse (internal) 6.3 A H (slow)
Refrigerant circuit
Refrigerant R 407 C
Fill volume kg 2.9 3.2
Compressor Type Hermetically sealed scroll compressor with injection
Dimensions
Total length mm 650 650
Total width mm 600 600
Total height mm 945 945
Permissible operating pressure
Groundwater circuit (primary) bar 4 4
Heating water circuit (secondary) bar 4 4
Intermediate circuit for indirect
operation
bar 4 4
Connections
Primary IN and OUT R 1¼" 1¼"
Heating flow and return R 1" 1"
Weight kg 145 165
5822 119-7 GB
VITOCAL 300/350 VIESMANN 9
*1
Operating point to DIN EN 255: W10 = groundwater i nlet temperature 10 °C/W35 = heating water outlet temperature 35 °C.
Operating point: W8 = groundwater inlet temperature 8 °C/W55 = heating water outlet temperature 55 °C.
Operating point: W8 = groundwater inlet temperature 8 °C/W65 = heating water outlet temperature 65 °C.
For further operating points, see the output diagrams.
*2
Always safeguard the min. throughput.
*3
With starting current limiter.
Specification (cont.)
