119
Model Combi boiler System boiler
(heat only)
Type L1P20 - A1JF N1P20 - A1GF
Rated heat input (heating mode) kW 5.7 - 20.4 5.7 - 20.4
Rated heat input (DHW heating) kW 5.7 - 22.8 –
Permiss. operating pressure (heating
water side)
MPa 0.08 - 0.3 0.08 - 0.3
Heating water temperature
Min. °C 40 40
Max. °C 76 76
Operating pressure (on the DHW side)
Min. MPa 0.1 –
Max. MPa 1.0 –
Nominal water flow rate for DHW
heating (ΔT = 30 K)
l/min 9.6 –
DHW temperature
Min. °C 30 –
Max. °C 57 –
Balanced flue connection
7 mm
60/100 60/100
IP rating IPX4D IPX4D
Rated voltage V 220 220
Rated frequency Hz 50 50
Rated current A 2.5 2.5
Protection class I I
Permissible ambient temperature
■ During operation °C 0 to +40 °C 0 to +40 °C
■ During storage and transport °C -25 to +65 °C -25 to +65 °C
Electronic temperature limiter setting °C 84 84
Temperature limiter setting °C 100 100
Dimensions
■ Length mm 300 300
■ Width mm 350 350
■ Height mm 700 700
Weight (net) kg 29.0 27.5
Specification
Rated heating output 18 kW
(cont.)
5837146
