125
Note
The supply values are only for refer-
ence (e.g. in the gas contract applica-
tion) or for a supplementary, rough esti-
mate to check the volumetric settings.
Due to factory settings, the gas pres-
sure must not be altered from these
values.
Model Combi boiler System boiler
Type L1P33 - A1JE N1P33 - A1HE
Rated heat input (heating mode) kW 8.5 - 33.3 8.5 - 33.3
Rated heat input (DHW heating) kW 8.5 - 33.3 8.5 - 33.3
Rated heating output (heating mode) kW 7.5 - 30.0 7.5 - 30.0
Rated heating output (DHW heating) kW 7.5 - 30.0 7.5 - 30.0
Sound power level dB (A) < 51 < 51
Gas throughput relative to max. heat-
ing output
m
3
/h
3.63 3.63
Natural gas 12T l/min 60.5 60.5
Nozzle pressure at max. heating output
Natural gas 12T
Pa 1580 1580
Gas throughput relative to min. heating
output
m
3
/h
0.89 0.89
Natural gas 12T l/min 14.8 14.8
Nozzle pressure at min. heating output
Natural gas 12T
Pa 100 100
Gas supply pressure
Natural gas 12T
Pa 2000 2000
NOx Class 3 3
Max. power consumption
(incl. circulation pump)
W 150 150
Boiler water capacity l 1.35 1.25
Diaphragm expansion vessel
Capacity l 10 10
Pre-charge pressure MPa 0.1 0.1
Permiss. operating pressure (heating
water side)
MPa 0.08 - 0.3 0.08 - 0.3
Heating water temperature
Min. °C 40 40
Max. °C 76 76
Specification
Rated heating output 30 kW
5837146
