Model Combi boiler System boiler
Type L1P33 - A1JE N1P33 - A1HE
Rated heat input (heating mode) kW 8.5 - 33.3 8.5 - 33.3
Rated heat input (DHW heating) kW 8.5 - 33.3 8.5 - 33.3
Operating pressure (on the DHW side)
Min. MPa 0.1 -
Max. MPa 1.0 -
Nominal water flow rate for DHW
heating (ΔT = 30 K)
l/min 14.4 -
DHW temperature
Min. °C 30 30
Max. °C 57 60
Balanced flue connection
7 mm
60/100 60/100
IP rating IPX4D IPX4D
Rated voltage V 220 220
Rated frequency Hz 50 50
Rated current A 2.5 2.5
Protection class I I
Permissible ambient temperature
■ During operation °C -5 to +40 °C -5 to +40 °C
■ During storage and transport °C -25 to +65 °C -25 to +65 °C
Electronic temperature limiter setting °C 84 84
Temperature limiter setting °C 100 100
Dimensions
■ Length mm 350 350
■ Width mm 480 480
■ Height mm 725 725
Weight (net) kg 35.0 34.0
Specification
Rated heating output 30 kW
