5.3Overview of stress reactions for Vitosol 100
100
VITOSOL
Type w 2.5  Collector angle of inclination 25º (details in kN)
Snow
Height above sea level
load
zone
*
1
m up to 200 up to 300 up to 400 up to 500
zone
*1
Building
height m
0−8 8−20 20−100 > 100 0−8 8−20 20−100 > 100 0−8 8−20 20−100 > 100 0−8 8−20 20−100 > 100
1
max. Av 1.05 1.10 1.15 1.18
1
assoc. Bv 2.07 2.21 2.35 2.45
assoc. Ah 0.12 0.19 0.26 0.30
assoc. Av 1.05 1.10 1.15 1.18
max. Bv see up to 500 m see up to 500 m see up to 500 m 2.07 2.21 2.35 2.45
assoc. Ah 0.12 0.19 0.26 0.30
min. Av −0.19 −0.46 −0.73 −0.91
assoc. Bv −0.84 −1.64 −2.44 −3.00
assoc. Ah −0.65 −1.04 −1.43 −1.69
assoc. Av −0.19 −0.46 −0.73 −0.91
min. Bv −0.84 −1.64 −2.44 −3.00
assoc. Ah −0.65 −1.04 −1.43 −1.69
2
max. Av 1.19 1.24 1.29 1.32
2
assoc. Bv 2.34 2.48 2.62 2.72
assoc. Ah 0.12 0.19 0.26 0.30
assoc. Av 1.19 1.24 1.29 1.32
max. Bv see up to 500 m see up to 500 m see up to 500 m 2.34 2.48 2.62 2.72
assoc. Ah 0.12 0.19 0.26 0.30
min. Av −0.19 −0.46 −0.73 −0.91
assoc. Bv −0.84 −1.64 −2.44 −3.00
assoc. Ah −0.65 −1.04 −1.43 −1.69
assoc. Av −0.19 −0.46 −0.73 −0.91
min. Bv −0.84 −1.64 −2.44 −3.00
assoc. Ah −0.65 −1.04 −1.43 −1.69
3
max. Av 1.29 1.34 1.39 1.42 1.52 1.57 1.62 1.65
3
assoc. Bv 2.51 2.66 2.80 2.89 2.96 3.10 3.25 3.34
assoc. Ah 0.12 0.19 0.26 0.30 0.12 0.19 0.26 0.30
assoc. Av 1.29 1.34 1.39 1.42 1.52 1.57 1.62 1.65
max. Bv see up to 400 m see up to 400 m 2.51 2.66 2.80 2.89 2.96 3.10 3.25 3.34
assoc. Ah 0.12 0.19 0.26 0.30 0.12 0.19 0.26 0.30
min. Av −0.19 −0.46 −0.73 −0.91 −0.19 −0.46 −0.73 −0.91
assoc. Bv −0.84 −1.64 −2.44 −3.00 −0.84 −1.64 −2.44 −3.00
assoc. Ah −0.65 −1.04 −1.43 −1.69 −0.65 −1.04 −1.43 −1.69
assoc. Av −0.19 −0.46 −0.73 −0.91 −0.19 −0.46 −0.73 −0.91
min. Bv −0.84 −1.64 −2.44 −3.00 −0.84 −1.64 −2.44 −3.00
assoc. Ah −0.65 −1.04 −1.43 −1.69 −0.65 −1.04 −1.43 −1.69
4
max. Av 1.29 1.34 1.39 1.42 1.43 1.48 1.53 1.56 1.80 1.85 1.90 1.93 2.32 2.37 2.42 2.45
4
assoc. Bv 2.51 2.66 2.80 2.89 2.78 2.93 3.07 3.16 3.50 3.64 3.78 3.88 4.48 4.62 4.76 4.86
assoc. Ah 0.12 0.19 0.26 0.30 0.12 0.19 0.26 0.30 0.12 0.19 0.26 0.30 0.12 0.19 0.26 0.30
assoc. Av 1.29 1.34 1.39 1.42 1.43 1.48 1.53 1.56 1.80 1.85 1.90 1.93 2.32 2.37 2.42 2.45
max. Bv 2.51 2.66 2.80 2.89 2.78 2.93 3.07 3.16 3.50 3.64 3.78 3.88 4.48 4.62 4.76 4.86
assoc. Ah 0.12 0.19 0.26 0.30 0.12 0.19 0.26 0.30 0.12 0.19 0.26 0.30 0.12 0.19 0.26 0.30
min. Av −0.19 −0.46 −0.73 −0.91 −0.19 −0.46 −0.73 −0.91 −0.19 −0.46 −0.73 −0.91 −0.19 −0.46 −0.73 −0.91
assoc. Bv −0.84 −1.64 −2.44 −3.00 −0.84 −1.64 −2.44 −3.00 −0.84 −1.64 −2.44 −3.00 −0.84 −1.64 −2.44 −3.00
assoc. Ah −0.65 −1.04 −1.43 −1.69 −0.65 −1.04 −1.43 −1.69 −0.65 −1.04 −1.43 −1.69 −0.65 −1.04 −1.43 −1.69
assoc. Av −0.19 −0.46 −0.73 −0.91 −0.19 −0.46 −0.73 −0.91 −0.19 −0.46 −0.73 −0.91 −0.19 −0.46 −0.73 −0.91
min. Bv −0.84 −1.64 −2.44 −3.00 −0.84 −1.64 −2.44 −3.00 −0.84 −1.64 −2.44 −3.00 −0.84 −1.64 −2.44 −3.00
assoc. Ah −0.65 −1.04 −1.43 −1.69 −0.65 −1.04 −1.43 −1.69 −0.65 −1.04 −1.43 −1.69 −0.65 −1.04 −1.43 −1.69
