3.1Calculating the required collector surface area
38
VITOSOL
3.1 Calculating the required collector surface area
DHW loading/heating
Collector area
Estimates based on meteorological
conditions such as annual global
radiation, cloud cover etc. are sufficiently
accurate for practical purposes. In order
to obtain a comprehensive summary of
the solar coverage for DHW loading, it is
recommended that this estimate should
form the basis of a calculation carried out
using the Viessmann computation
program (available on request from our
sales branch).
The coverage determined by this
program should be 50 to 60
% for
relatively small systems (detached
house), and at least 30 to 40
% for larger
systems from approx. 30 m
2
(apartment
block).
Guide values for estimating the required
collector area can be drawn from the
table on page40.
The collector area calculated on the basis
of this table has proved to be accurate in
practice.
DHW cylinder capacity (solar calorifier)
The following values can be used as a
basis for calculating the cylinder storage
capacity (according to VDI2067):
Hot water
requirement
V
p
litres/(d·person)
(DHW
temp. 45 ºC)
Residential properties
*1
High requirements
Average requirements
Basic requirements
Hotels, guest houses,
residential homes
Room with bath and
shower
Room with bath
Room with shower
Residential homes,
guest houses
60100
30
60
15
30
170
260
135
196
74
135
3774
*1
Empirical value: 30to50litres/(d·person)
The total DHW cylinder capacity (solar
calorifier capacity
+standby reservoir
capacity) should be sized on the basis of
1.5 to 2 times the daily requirements:
V
cyl
min
=
2  V
p
 P  (t
w
 t
k
)
t
cyl
 t
k
V
cyl
min
= min. cylinder capacity in litres
empirical value:
75 to 100litres/(d·person),
including standby volume
V
p
= hot water requirement in
litres/(d·person)
(acc. to the table on the left)
P = number of persons
t
w
= hot water temperature at the
tap
t
k
= cold water temperature
t
cyl
= temperature of the hot water
inside the DHW cylinder
(50 to 60 ºC)
Swimming pool water heating
The heat demand for swimming pools
depends on the nature of the swimming
pool (indoor or outdoor), its cover and its
location.
With outdoor pools, the heat requirement
is substantially influenced by fluctuations
in the air temperature, variable cloud
cover, the thermal insulation of the
swimming pool and the required pool
water temperature.
With indoor pools, the heat demand is
influenced by ventilation, humidity, air
temperature and the required pool water
temperature.
If you want to maintain the pool water
temperature (i.e. not heat it up), it is
possible to use the guide values for
calculating the collector area in
conjunction with the heat exchanger area
(see table on page40).
