4.8Additional Vitosolic 200 functions
84
VITOSOL
4.8 Additional Vitosolic 200 functions
Summary
Further functions may be added to each system design.
Functions for which the same relay output is used can only be utilised alternately.
Options
Relay Possible with design
p
y
1 3 4 5 6 7
Bypass version R5
1  with collector and bypass sensor x x
*1
x x
*1
x x
2  with solar cell      x
3  with solar cell and collector temperature sensor x x
*1
x x
*1
x x
External heat exchanger R2 x  x
*2
 x
*2

Cooling function  x x x x x x
Special functions of tube collectors  x x x x x x
Collector cooling function  x x x x x x
Reverse cooling function  x x x x x x
Frost protection  x x x x x x
Parallel relay R5 x x x x x x
Reloading suppression R7 x x x x x x
Cylinder 2 ON R4  x  x  
Additional function for DHW heating R5 x x x x x x
DHW loading R6 x   x  
Thermostat 1 R3 x  x  x 
Thermostat 2 x  x  x 
T5 control unit x  x  x 
Time switch 1 x  x  x 
Thermostat 3 R6 x     
Thermostat 4 x   x  
T6 control unit x     
Time switch 2 x     
Thermostat 5 R7 x x x x x x
Thermostat 6 x x x x x x
T7 control unit x x x x x x
Time switch 3 x x x x x x
*1
Connect bypass sensor to S7.
*2
Connect bypass sensor (external heat exchanger sensor) to S8.
