3.2Sizing pipe diameters and circulation pump
45
VITOSOL
Installation examples for Vitosol 200 vacuum tube collectors
Installation on walls, balconies or flat roofs (up to 6m
2
absorber area)
To optimise the whole system (better start−up characteristics), we recommend the bypass circuit (see system designs) for these types
of installation.
Connection on alternate sides
(preferred option)
Single−sided connection from below Single−sided connection from above
Installation of typeD
10 on walls, balconies and balustrades
Connection on alternate sides (preferred option)
Single−sided connection from below
A Flow
B Return
C Air vent valve
5822135 GB
A
C
B
18x1
18x1
18x1
C
B
A
C
A
B
18x1
C C C
A
B
15x1
15x1
15x1
C C C
A
B
