4.1System design1  with Vitosolic 200
64
VITOSOL
Control equipment required
Item
Description Number Part no.
Control of DHW cylinder loading by solar energy
1 Vitosolic 200 1 7170926
2 Collector temperature sensor 1 Included in the
delivery for item1
3 Cylinder temperature sensor
*1
1 Included in the
delivery for item1
4 Solar circuit pump (standard delivery of Solar−Divicon, (see page 51) 1 7170931
or
7170932
5 High limit safety cut−out, (see page 57)
*2
1 Z001889
8 Circulation pump (relayering) 1 Vitoset price list
Control of DHW cylinder loading by the boiler
6 Cylinder temperature sensor 1 Included in the
delivery of boiler
control unit
*3
7 Cylinder loading pump
*4
1 DHW cylinder
accessory
*1
Installation requires a threaded elbow (standard delivery for VitocellB100, accessory for Vitocell−B 300 ).
*2
The cylinder locking cap, which is available as an accessory for the DHW cylinder, is required for installation in VitocellB300;
observe the max. connectable aperture area with VitocellB100 (see page40).
*3
For Vitodens, Vitopend and Vitoplus accessories.
*4
Standard delivery for Vitodens, Vitopend and Vitoplus.
