ViewSonic PG603W User Manual

54
Function Description
Audio Settings See "Adjusting the sound" on page 42 for details.
Presentation
Timer
See "Setting the presentation timer" on page 31 for details.
Pattern
The projector can display several test patterns. It helps you
adjust the image size and focus and check that the projected
image is free from distortion.
Blank Timer See "Hiding the image" on page 33 for details.
Message
Selecting On displays the current information on the screen
when the projector is detecting or searching for a signal.
Splash Screen
Allows you to select which logo screen will be displayed
during projector start-up.
3D Settings See "Using the 3D functions" on page 34 for details.
HDMI Settings See "Changing HDMI input settings" on page 24 for details.
Lamp Settings
Lamp Mode
See "Setting Lamp Mode" on page 59 for details.
Reset Lamp Hours
Resets the lamp timer after new lamp is installed. For
changing the lamp, please contact qualified service personnel.
Lamp Hours
See "Getting to know the lamp hour" on page 59 for details on
how the total lamp hour is calculated.
LAN Control
Settings
See "Controlling the projector through a LAN environment"
on page 35 for details.
Filter Settings
See "Using the dust filter (optional accessory)" on page 57 for
details.
DCR
Enables or disables the DCR (Dynamic Contrast Ratio)
function. Selecting On enables the function and the projector
will automatically switch the lamp mode according to the
input image detected.
This function is only available when a PC input signal is
selected.
After enabling DCR, frequent lamp mode switching may
shorten lamp life and noise level will vary during
operation.
4. BASIC menu
5. ADVANCED menu

ViewSonic PG603W Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1 - 11 m
Vertical scan range	23 - 120 Hz
Horizontal scan range	15 - 102 kHz
Projection technology	DLP
Contrast ratio (dynamic)	22000:1
Contrast ratio (typical)	-
Screen size compatibility	30 - 300 \
Projector native resolution	720p (1280x720)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	-20 - 20 °
RMS rated power	10 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	15000 h
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	270 W
Throw ratio	1.55 - 1.7
Optical zoom	1.1 x
Focal length range	- mm
Supported graphics resolutions	640 x 480 (VGA), 1920 x 1080 (HD 1080)
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Noise level	- dB
Certification	FCC, cTUVus, NOM
Cables included	AC, VGA
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	218 mm
Width	294 mm
Height	110 mm
Weight	2300 g
Package depth	300 mm
Package width	365 mm
Package height	188 mm
Package weight	3300 g
