ViewSonic PG603W User Manual

55
Function Description
Reset Settings
Returns all settings to the factory preset values.
The following settings will still remain: Keystone, Phase,
H. Size, OverScan, Language, Projector Position, High
Altitude Mode, Security Settings, Remote Control Code,
3D Sync, Filter Mode, HDMI Settings.
Language
Sets the language for the On-Screen Display (OSD) menus.
See "Using the menus" on page 21 for details.
Projector
Position
See "Choosing a location" on page 12 for details.
Menu Settings
Menu Display Time
Sets the length of time the OSD will remain active after your
last key press. The range is from 5 to 30 seconds in 5-second
increments.
Menu Position
Sets the On-Screen Display (OSD) menu position.
High Altitude
Mode
A mode for operation in high altitude areas. See "Operating in
a high altitude environment" on page 33 for details.
Quick Auto
Search
See "Switching input signal" on page 24 for details.
Security
Settings
See "Utilizing the password function" on page 22 for details.
Panel Key Lock See "Locking control keys" on page 33 for details.
Remote Control
Code
See "Remote control code" on page 9 for details.
Baud Rate
Selects a baud rate that is identical with your computer’s so
that you can connect the projector using a suitable RS232
cable and control the projector with RS232 commands.
5. ADVANCED menu
6. SYSTEM menu

ViewSonic PG603W Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1 - 11 m
Vertical scan range	23 - 120 Hz
Horizontal scan range	15 - 102 kHz
Projection technology	DLP
Contrast ratio (dynamic)	22000:1
Contrast ratio (typical)	-
Screen size compatibility	30 - 300 \
Projector native resolution	720p (1280x720)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	-20 - 20 °
RMS rated power	10 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	15000 h
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	270 W
Throw ratio	1.55 - 1.7
Optical zoom	1.1 x
Focal length range	- mm
Supported graphics resolutions	640 x 480 (VGA), 1920 x 1080 (HD 1080)
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Noise level	- dB
Certification	FCC, cTUVus, NOM
Cables included	AC, VGA
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	218 mm
Width	294 mm
Height	110 mm
Weight	2300 g
Package depth	300 mm
Package width	365 mm
Package height	188 mm
Package weight	3300 g
