ViewSonic PG603W User Manual

66
<RS232 command table>
Function Status Action cmd
Power
Write
Turn on 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x00 0x00 0x5D
Turn off 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x01 0x00 0x5E
Read
Power status
(on/off)
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x00 0x5E
Reset all
settings
Execute 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x02 0x00 0x5F
Reset Color
Settings
Execute 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x2A 0x00 0x87
Splash
Screen
Write
Splash Screen
Black
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x00 0x67
Splash Screen
Blue
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x01 0x68
Splash Screen
ViewSonic
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x02 0x69
Splash Screen
Off
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0A 0x04 0x6B
Read
Splash Screen
status
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x0A 0x68
Quick
Power Off
Write
Quick Power
Off Off
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0B 0x00 0x68
Quick Power
Off On
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0B 0x01 0x69
Read
Quick Power
Off status
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x0B 0x69
High
Altitude
Mode
Write
High Altitude
Mode Off
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0C 0x00 0x69
High Altitude
Mode On
0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x0C 0x01 0x6A
Read
High Altitude
Mode status
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x0C
0x6A
Lamp Mode
Write
Normal 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x00 0x6D
Eco 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x01 0x6E
Dynamic 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x02 0x6F
SuperEco 0x06 0x14 0x00 0x04 0x00 0x34 0x11 0x10 0x03 0x70
Read
Lamp Mode
status
0x07 0x14 0x00 0x05 0x00 0x34 0x00 0x00 0x11 0x10 0x6E

ViewSonic PG603W Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1 - 11 m
Vertical scan range	23 - 120 Hz
Horizontal scan range	15 - 102 kHz
Projection technology	DLP
Contrast ratio (dynamic)	22000:1
Contrast ratio (typical)	-
Screen size compatibility	30 - 300 \
Projector native resolution	720p (1280x720)
Keystone correction, vertical	-30 - 30 °
Keystone correction, horizontal	-20 - 20 °
RMS rated power	10 W
Placement	Desktop
Product type	Standard throw projector
Product color	White
Lamp power	200 W
Light source type	Lamp
Service life of light source	5000 h
Service life of light source (economic mode)	15000 h
Built-in display	No
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	270 W
Throw ratio	1.55 - 1.7
Optical zoom	1.1 x
Focal length range	- mm
Supported graphics resolutions	640 x 480 (VGA), 1920 x 1080 (HD 1080)
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 90 %
Noise level	- dB
Certification	FCC, cTUVus, NOM
Cables included	AC, VGA
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	218 mm
Width	294 mm
Height	110 mm
Weight	2300 g
Package depth	300 mm
Package width	365 mm
Package height	188 mm
Package weight	3300 g
