ViewSonic PJD6352 User Manual

7
Controls and functions
Projector
1. Focus ring
Adjusts the focus of the projected image.
2. Zoom ring
Adjusts the size of the projected image.
3. Menu
Turns on the On-Screen Display (OSD)
menu.
Exit
Goes back to previous OSD menu, exits
and saves menu settings.
4. / / / (Keystone keys)
Manually corrects distorted images
resulting from an angled projection.
Left/ Right/ Up/ Down
Selects the desired menu items and makes
adjustments.
5. Power
Toggles the projector between standby
mode and Power ON.
6. Source
Displays the source selection bar.
(Help)
Displays the HELP menu by a long press
for 3 seconds.
7. Enter
Enacts the selected On-Screen Display
(OSD) menu item.
Displays the Corner Adj. page.
8. (My Button)
Allows user to define a short cut key on
this button, and the function item is
selected in OSD menu.
9. (Power indicator light)
Lights up or flashes when the projector is
under operation.
10. (Temperature indicator light)
Lights up red if the projector's
temperature becomes too high.
11. (Lamp indicator light)
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem.
12. Color Mode
Selects an available picture setup mode.
1
PJD6350/PJD6352
PJD6550Lw/PJD6552Lw
PJD6351Ls/PJD6352Ls
PJD6551Lws/PJD6552Lws
3
4
5
6
7
4
8
9
10
11
4
12
4
1
2
3
4
5
6
7
4
8
9
10
11
4
12
4

ViewSonic PJD6352 Specifications

General

Noise Level	32 decibels
White Brightness	3500 lumens
Native Resolution	1024 x 768
Contrast Ratio	22000:1
Aspect Ratio	4:3
Throw Ratio Range	1.51 - 1.97:1
3D	yes
Minimum Screen Size	29.9 inches
Maximum Screen Size	300 inches
Focus Adjustment	manual
Minimum Distance	3.3 feet
Maximum Distance	33 feet
Video Input	composite video, hdmi, s-video, vga
Inputs	3.5mm audio, composite video, din, hdmi, mini-usb, rca, s-video, vga
Sound Mode	mono
Built In Speakers	yes
Speakers Output	10 watts
Remote Control	yes
OS Compatibility	windows, mac

Weight and Dimensions

Depth	9 inches
Height	4.1 inches
Width	12.4 inches
Net Weight	5.1 pounds
