ViewSonic PJD6352 User Manual

8
Remote control
To use the remote mouse control keys
(Page Up, Page Down, , and
), see
"Using the remote mouse control" on
page 10 for details.
1. Power
Toggles the projector between standby
mode and Power ON.
2. Source selection keys
• COMP1/COMP2
Selects D-Sub / Comp. 1 or D-Sub /
Comp. 2 source for display.
• HDMI
Selects HDMI source for display.
3. Auto Sync
Automatically determines the best
picture timings for the displayed
image.
4. / / / (Keystone keys)
Manually corrects distorted images
resulting from an angled projection.
Left/ Right/ Up/ Down
Selects the desired menu items and
makes adjustments.
5. Enter
Enacts the selected On-Screen Display
(OSD) menu item.
Displays the Corner Adj. page.
6. Menu
Turns on the On-Screen Display
(OSD) menu.
7. (Left mouse button)
Performs the same function as the left
mouse button when the mouse mode is
activated.
Only available when a PC input signal
is selected.
8. (Right mouse button)
Performs the same function as the
right mouse button when the mouse
mode is activated.
Only available when a PC input signal
is selected.
COMP1 COMP2 HDMI
Source
PgUp
Mouse Pattern Blank
PgDn
Eco
Mode
Color
Mode
Audio
Mode
Auto
Sync
Menu Exit
Enter
1
2
6
7
3
4
15
16
18
21
22
14
17
19
20
25
23
26
24
5
8
12
9
13
10
11
4
4
4

ViewSonic PJD6352 Specifications

General

Noise Level	32 decibels
White Brightness	3500 lumens
Native Resolution	1024 x 768
Contrast Ratio	22000:1
Aspect Ratio	4:3
Throw Ratio Range	1.51 - 1.97:1
3D	yes
Minimum Screen Size	29.9 inches
Maximum Screen Size	300 inches
Focus Adjustment	manual
Minimum Distance	3.3 feet
Maximum Distance	33 feet
Video Input	composite video, hdmi, s-video, vga
Inputs	3.5mm audio, composite video, din, hdmi, mini-usb, rca, s-video, vga
Sound Mode	mono
Built In Speakers	yes
Speakers Output	10 watts
Remote Control	yes
OS Compatibility	windows, mac

Weight and Dimensions

Depth	9 inches
Height	4.1 inches
Width	12.4 inches
Net Weight	5.1 pounds
