Viking DSOE305T - Page 21

© 2010 Viking Preferred Service
21
Diagnostics
Service Diagnostics and Testing
1. Run all Tests (cont.)
Step Test Result To Change Test
15 Upper Convection Fan – Low speed
reverse
Run convection fan at low speed reverse*
* Oven uses a single direction convection
motor (Same direction as low speed)
Enter, Up or Down arrow
16 Upper Convection – High speed
reverse
Run convection fan at high speed reverse*
* Oven uses a single direction convection
motor. (Same direction as high speed)
Enter, Up or Down arrow
17 Upper Door Switch Check door interlock Enter, Up or Down arrow
18 Upper Oven Lights Check upper cavity lights Enter, Up or Down arrow
19 Upper Door Lock Door lock motor advanced Door must lock to
advance
20 Upper Door Unlock Engage door lock to unlock door Door must unlock to
advance
21 Lower Inner Bake Element SKIP THIS TEST
(No amperage should be read on Step 1.
Not used on DSOE and DDOE models)
Enter, Up or Down arrow
22 Lower Outer Bake Element Run Bake Element *** Enter, Up or Down arrow
23 Lower Inner Broil Element Run inner broil element Enter, Up or Down arrow
24 Lower Outer Broil Element Run outer broil element Enter, Up or Down arrow
25 Lower Convection Element Run convection element Enter, Up or Down arrow
26 Lower Oven Temperature Display lower oven temperature Enter, Up or Down arrow
27 Lower Meat Probe SKIP THIS TEST
(No lower meat probe on the DDOE305T)
Default 0 degrees
Enter, Up or Down arrow
28 Lower Cooling Fan – High speed Run cooling fan at high speed Enter, Up or Down arrow
29 Lower Cooling Fan – Low speed Run cooling fan at low speed*
* Oven uses a single speed motor (same
RPM’s as high speed)
Enter, Up or Down arrow
30 Lower Convection Fan – High speed Same as Upper Convection Fan Enter, Up or Down arrow
31 Lower Convection Fan – Low speed Same as Upper Convection Fan Enter, Up or Down arrow
32 Lower Convection Fan – Low speed
reverse
Same as Upper Convection Fan Enter, Up or Down arrow
33 Lower Convection Fan – High
speed reverse
Same as Upper Convection Fan Enter, Up or Down arrow
34 Lower Door Switch Check door interlock Enter, Up or Down arrow
35 Lower Oven Lights Check lower cavity lights Enter, Up or Down arrow
36 Lower Door Lock Door lock motor activated Door must lock to
advance
37 Lower Door Unlock Engage door lock to unlock door Door must unlock to
advance
***If no amperage is read, check STEP 21 (Inner Bake Element). If amperage is read, the plug on the
relay board is reversed.
