Diagnostics
Service Diagnostics and Testing
8. Run all lower oven tests (DSOE350T – cont.)
Step Test Result To Change Test
3 Lower Inner Broil Element Run inner broil element Enter, Up or Down arrow
4 Lower Outer Broil Element Run outer broil element Enter, Up or Down arrow
5 Lower Convection Element Run convection element Enter, Up or Down arrow
6 Lower Oven Temperature Display lower oven temp Enter, Up or Down arrow
7 Lower Meat Probe SKIP THIS TEST
(No lower meat probe on DDOE305T )
Enter, Up or Down arrow
8 Lower Cooling Fan – High speed Run cooling fan high speed Enter, Up or Down arrow
9 Lower Cooling Fan – Low speed Run cooling fan at low speed*
* Oven uses a single speed motor (same
RPM’s as high speed)
Enter, Up or Down arrow
10 Lower Convection Fan – High speed Run convection fan high speed Enter, Up or Down arrow
11 Lower Convection Fan – Low speed Run convection fan low speed Enter, Up or Down arrow
12 Lower Convection Fan – Low speed
reverse
Run convection fan at low speed reverse*
* Oven uses a single direction convection
motor (Same direction as low speed)
Enter, Up or Down arrow
13 Lower Convection Fan – High speed
reverse
Run convection fan at high speed
reverse*
* Oven uses a single direction convection
motor (Same direction as low speed)
Enter, Up or Down arrow
14 Lower Door Switch Check door interlock Enter, Up or Down arrow
15 Lower Oven Lights Check lower cavity lights Enter, Up or Down arrow
16 Lower Door Lock Door lock motor is advanced Enter, Up or Down arrow
17 Lower Door Unlock Engage door lock to unlock door Enter, Up or Down arrow
To end the test, press the “CLEAR” pad.
9. Run all keyboard tests
This test is similar to RUN ALL TESTS with the exception that only the keyboard pads are tested. This test
will cycle through all the touch key pads on the control panel in succession, starting with the Bake pad.
As you press the designated pad, a successful input will be followed by a single tone and the display will
prompt the user as to the next keypad to depress. A double tone will indicate the designated pad was not
pressed. To begin the test, select either the “SET” or “ENTER” pad.
Below is a table consisting of all the individual key pads that can be tested in this program.
Step Test Result
1 Press BAKE pad Pressing Bake pad will advance to next test
2 Press BROIL pad Pressing Broil pad will advance to next test
3 Press TRU CONVEC pad Pressing Tru Convec pad will advance to next test
