Diagnostics
Service Diagnostics and Testing
4. Individual upper oven tests (DDOE305T – cont.)
Individual oven tests (DSOE305T – cont.)
The following is a table consisting of all the individual components that can be tested in this program.
To scroll through each test, use the “UP ARROW” or “DOWN ARROW” pad, and then press “SET” or
“ENTER” to run the selected component test.
Step To test: Test Result To exit:
1 Press SET Inner Bake Element SKIP THIS TEST
(No amperage should be read on Step 1.
Not used on DSOE and DDOE models)
Enter, Clear, or
Down arrow
2 Press SET Outer Bake Element Run Bake Element*** Enter, Clear, or
Down arrow
3 Press SET Inner Broil Element Run inner broil element Enter, Clear, or
Down arrow
4 Press SET Outer Broil Element Run outer broil element Enter, Clear, or
Down arrow
5 Press SET Convection Element Run convection element Enter, Clear, or
Down arrow
6 Press SET Oven Temperature Display upper oven temp Enter, Clear, or
Down arrow
7 Press SET Meat Probe Displays meat probe temp with probe
inserted in socket (default is 0°F with no
probe inserted)
Enter, Clear, or
Down arrow
8 Press SET Cooling Fan – High speed Run cooling fan high speed Enter, Clear, or
Down arrow
9 Press SET Cooling Fan – Low speed Run cooling fan low speed Enter, Clear, or
Down arrow
10 Press SET Convection Fan – High
speed
Run convection fan high speed Enter, Clear, or
Down arrow
11 Press SET Convection Fan – Low
speed
Run convection fan low speed Enter, Clear, or
Down arrow
12 Press SET Convection Fan – Low
speed reverse
Run convection fan at low speed reverse*
* Oven uses a single direction
convection motor.
(Same direction as high speed)
Enter, Clear, or
Down arrow
13 Press SET Convection Fan – High
speed reverse
Run convection fan at high speed reverse*
* Oven uses a single direction
convection motor.
(Same direction as high speed)
Enter, Clear, or
Down arrow
14 Press SET Door Switch Check door interlock Enter, Clear, or
Down arrow
15 Press SET Oven Lights Check upper cavity lights Enter, Clear, or
Down arrow
16 Press SET Door Lock Engage door lock to lock door Enter, Clear, or
Down arrow
***If no amperage is read, check STEP 1 (Inner Bake Element). If amperage is read, the plug on the relay board
is reversed.
