Viking VGSC548 - Oven Components - LH Oven

Troubleshooting
16 ©2010 Viking Preferred Service
Oven Components - LH Oven
Symptom Possible Cause Corrective Action
LH oven, RH oven, oven lights, sur-
face burner, grill, and griddle igniters
inoperable
House breaker or fuse open Reset breaker or replace fuse
Open high limit Replace high limit
Defective oven wiring (shorted,
open, or burned)
Repair or replace defective wiring
LH oven inoperable - RH oven,
oven lights, surface burner, grill, and
griddle igniters operate
Foreign objects/soil on igniter Clean igniter and surrounding area
Open bake solenoid valve Replace bake solenoid valve or dual
solenoid valve
Open thermostat Replace thermostat
Open direct spark module Replace direct spark module
Defective oven wiring (shorted,
open, or burned)
Repair or replace defective wiring
Oven lights inoperable - LH oven,
RH oven, surface burner, grill, and
griddle igniters operate
Open oven bulbs Replace oven bulbs
Open light switch Replace light switch
Open door light switch Replace door light switch
Defective oven wiring (shorted,
open, or burned)
Repair or replace defective wiring
Oven cycle light inoperable - RH
oven, LH oven, surface burner, grill,
and griddle igniters operate
Defective cycle light (neon) Replace cycle
light
Open thermostat Replace thermostat
Defective oven wiring (shorted,
open, or burned)
Repair or replace defective wiring
