Viking VGSC548 - Broil Burner Removal

Disassembly
44 ©2010 Viking Preferred Service
To avoid risk of electrical shock, personal injury, or death, disconnect electrical power source to unit, unless test
procedures require power to be connected. Discharge capacitor through a resistor before attempting to service.
Ensure all ground wires are connected before certifying unit as repaired and/or operational.
Broil Burner Removal
Condition Requirements:
Door Assembly Removed
Back Panel Removed
1. Remove nut from broil burner and gas tubing.
2. Remove two screws that secure igniter to oven
cavity.
3. Remove fi ve screws and rear broil burner bracket
from oven cavity.
4. Remove four screws and front broil burner bracket
from oven cavity.
5. Pull broil burner from range.
6. Reverse procedure for installation.
