vimec V65 B.R. User Manual

18
CONTENTS OF THE MANUAL
ASSEMBLY INSTRUCTIONS
1. System supply condition Page 19
2. Installing the lower rail Page 20
3. Installing the upper rail Page 22
4. Assembling the carriage Page 23
5. Positioning the charging station (if applicable) Page 25
6. Connecting the power supply unit Page 27
7. Connecting the installation engineer’s control panel Page 27
8. Fixing the connecting feet Page 29
9. Fitting the bars Page 30
10. Assembling the platform with driven front access Page 31
11. Assembling the platform Page 34
12. Preparing the stairlift for setup Page 36
13. Setting up the stairlift Page 37
14. Checks on installation Page 37
15. Adjusting rail bend rollers Page 38
16. Adjusting guide shoe supports Page 38
17. Fitting the over-run device cams Page 39
18.
Check the position of the over-run device cam and plates Page 40
19. Stretching the chain Page 40
20. Final testing Page 40
21. Fitting the casings Page 41
22. Fitting the caps and end covers Page 42
