3) DESCRIPTION OF THE STAIRLIFT
3.1) Description
Lift unit - Fig. 1
Comprises:
- carriage
- load-bearing structure
- safety bars - Fig. 1/a.
- load platform - Fig. 1/c.
- casing - Fig. 1/b.
- control board - Fig. 1/d.
Contains:
The control board carries the following controls:
- control enabling key with start button - Fig. 2/a.
- up/down buttons - Fig. 2/b.
- overload indicator light - Fig. 2/c (standard operated
only for 1250x800 and 1050x900 platforms).
- bell push-button - Fig. 2/d.
- emergency stop (red mushroom-head button) - Fig.
2/e.
- radio and stairlift tension indicator light - Fig. 2/g.
- floor selector button - Fig. 2/h
On the lift unit:
- connection for handwheel for manual operation -
Fig.2/f.
- motor - Fig. 3/a.
