Safety - Read This First!
Warning symbols in this maintenance manual
Where there is a risk of personal injury, injury to others, or damage to the pedestal or
associated equipment, comments appear, highlighted by the word WARNING! and
supported by the warning triangle symbol.
Warning symbols on the pedestal
On encountering the warning triangle and open book symbols it is imperative that you
consult this maintenance manual before using this pedestal or attempting any adjustment
or repair.
Critical data
Mass
Pedestal 173 kg (383 lb)
Trim weights (total) 7.5 kg (16.5 lb)
Load
Minimum Load 23 kg (50 lb)
Maximum Load 158 kg (350 lb)
Pressure
Maximum pressure 19.3 bar (280 psi)
158 kg
173 kg
≤19.3 bar
