Pressure Tank Assembly (Part No. 3702-42)
1
2
9
17
Standard: BS5500 - 1994- Category 2
Maximum Working Pressure 20.34 bar
(295 psi)
Design Pressure 22.4 bar
(325 psi)
Test Pressure 27.99 bar
(406 psi)
Volume 0.0318 m
3
(1940 in
3
)
Design Temperature 50°C
15
3
4
10
11
8
6
5
7
16
14
13
12
18
All welds
