Viofo A229 Pro - Product Diagram; Front Camera and GPS Module

Pro
7
6
5
4
3
1
2
Product Diagram
1 - Menu / Power On|Off
2
- Menu Up / Recording Start | Stop
3
- Menu Confirm / Video Protect / Playback
4
- Menu Down / Microphone On | Off
5
- Wi-Fi On | Off
6
- Memory Card Slot
7
- Interior Camera Port
1 - Rear Camera Port / Power In / microSD Card Reader
Mode (computer)
2 - Reset Button
3 - Power Status Indicator
4 - Recording Status Indicator
5 - GPS Status Indicator
6 - Microphone Status Indicator
7 - Wi-Fi Status Indicator
1 - USB Power Port
2 - Mount (GPS Module)
3 - Lens
Front Camera (Main Unit)
1
2
3
2 3
1
2
3
5
4
6
7
Pro
Bluetooth
Control
HK4
Hardwire Kit
MicroSD
Card
