4. Fix the rear camera on the selected location.
3. Peel the protection film off the sticky pad and camera lens.
Install the Rear Camera (Optional)
1. Select an installation location on the windscreen,
without defrost grid wires, and where the camera can
record the entire rear view.
2. Wipe clean the installation surface of the windscreen
with a dry cloth.
5. Connecting with Rear Camera
Power off the product and connect the rear camera
cable to the front camera (main unit).
Cable routing should be as shown in the following two
diagrams.
4. Fix the Interior camera on the selected location.
Install the Interior Camera (Optional)
1. Select an installation location.
2. Wipe clean the installation surface of the windscreen
with a dry cloth. Select a location on the windscreen,
without defrost grid wires, and where the camera can
record the entire Interior view.
3. Peel the protection film off the sticky pad and camera
lens.
1
2
Rear Camera
Front Camera
14 15
