6. Adjust the Lens Angle
- Look at the live view on the LCD.
- Adjust the angle of the lens up / down if necessary.
5. Fix the camera on the selected location.
7. Connecting to Power
Insert the car charger USB cable’s male port into the
camera mount's Type-C port. Plug the car charger
adapter into your vehicle’s 12V / 24V female power
socket.
2
1
3. Peel the green sign protective film off the static sticker.
1. Wipe clean the surface of the windscreen before
installation.
2. Peel the red sign protective film off the static sticker,
then attach the sticker to the windscreen. Press it for a
few seconds, making sure no bubbles are left.
Install the Static Sticker (Optional)
4. Peel the protection film off the sticky pad on the mount,
and attach it to the sticker. Press the camera hard for a
few seconds, making sure it is attached firmly.
12 13
