Application fields
With the help of this CPU series you can access the peripheral modules of
the System 300V from VIPA. You may request sensors and control actors
via standardized commands and programs. One CPU is able to manage a
maximum of 32 modules in one line.
Central compact solution
CPU
AI 8 AO 2
DIO 16
DO 16
CPU 31x
DO 32
DI 32
Decentral system via Profibus
4
input/output periphery
CPU 31x
6
input/output periphery
CPU 21x DP
CPU
IM 353
2
2
input/output periphery
IM 353
3
input/output periphery
CPU IM 208
2,5
IM 253
5
input/output periphery
System 300 System 200
CPU 31xDPM
3, 4, 6
Application
example
