VIPA System 300V - Project Engineering CPU with Integrated Profibus Master

Manual VIPA System 300V Chapter 5 Deployment CPU 31x with Profibus
HB130E - CPU - Rev. 11/50 5-3
Project engineering CPU with integrated Profibus master
For the project engineering of the Profibus DP master you have to use the
hardware manager from Siemens. Your Profibus projects are transferred
via MPI to the CPU 31xDPM by means of the "PLC" functions. The CPU
passes the data on to the Profibus DP master.
For the project engineering of the Profibus DP master in the CPU 31xDPM
the following preconditions have to be fulfilled:
• Hardware-Manager from Siemens has to be installed.
• With deployment of a DP Slave the appropriate GSD is to be installed. If
the slave system is a CPU 31x from VIPA no GSD is necessary.
• There is a transfer possibility between configuration tool and CPU 31x.
Note!
For the project engineering of the CPU and the Profibus DP master a
thorough knowledge of the STEP
®
7 manager and the hardware
configurator from Siemens is required!
The hardware configurator is a part of the STEP
®
7 projecting tool from
Siemens. It serves the project engineering. The modules that may be
configured here, are listed in the hardware catalog.
With deployment of a DP Slave the appropriate GSD is to be installed. If
the slave system is a CPU 31x from VIPA no GSD is necessary.
• Create a new project System 300.
• Add a profile rail from the hardware catalog.
• In the hardware catalog the CPU with Profibus master is listed as:
Simatic300/CPU-300/CPU315-2DP/6ES7 315-2AF03-0AB0
• Insert the CPU 315-2DP (6ES7 315-2AF03-0AB0).
• Type the Profibus address of your master (e.g. 2).
• Click on DP, choose the operating mode "DP master" at object
properties and confirm your entry with OK.
• Click on "DP" with the right mouse button and choose "add master
system".
• Create a new Profibus subnet via NEW.
Outline
Preconditions
Install Siemens
Hardware
configurator
Configure
DP master
