Manual VIPA System 300V Chapter 3 Hardware description
HB130E - CPU - Rev. 11/50 3-23
Technical Data
Electrical Data VIPA 314 ... VIPA 317
Power supply DC 24V
Current consumption max. 1.1A
Dissipation power max. 2W
Status display (LEDs) via LEDs on the frontside
Integrated Profibus-interface DP slave
Slots / Interfaces:
MP
2
I
Profibus
MP
2
I-interface for data transmission:
4 static / 8 dynamic connections(187kBaud)
RS232: 38,4kBaud
RS485 Profibus-DP slave
Battery buffer / clock yes / Lithium-Battery, 30 Days Buffer
Output voltage to backplane bus max. 3.5A
Bit memory 8192
Timers / Counters 256 / 256
Modules FBs 1024, FCs 1024
DBs 2047
Combination with peripheral modules
Max. number of modules 32
Max. digital E/A (I/O) 32
Max. analog E/A (I/O) 16
Addressable E/A (I/O)
digital channels
analog channels
1024
1024
Measurements and Weight
Measurements (HxWxL) in mm 80x125x120
Weight in g 200g
CPU 314 CPU 315 CPU 316 CPU 317
Program memory 96kByte 192kByte 256kByte 512kByte
Load memory 144kByte 256kByte 512kByte 1MB
Typical processing
time Bit/Word
(ms/k commands)
0.18 / 0.78 0.18 / 0.78 0.18 / 0.78 0.18 / 0.78
Order No.: VIPA 314-1SL01 VIPA 315-1SL01 VIPA 316-1SL01 VIPA 317-1SL01
CPU 31x
