Electrical Data VIPA 314 ... 317
Like CPU 31x additionally with
DP master
Status display (LEDs) like CPU 31x additionally with LEDs for the Profibus-DP
master
Profibus interface
Connection 9-pin SubD-slot
Network topology linear bus, active bus termination at both ends, tap line
possible
Medium isolated drilled twisted pair-cable, isolation may be left
depending on environmental conditions.
Transfer rate 9.6kBaud to 12MBaud
Total length without repeater 100m at 12Mbaud,
with repeater up to 1000m
Max. number of partners 32 stations in every segment without repeater;
with Repeater expandable to 126.
Measurements and Weight
Measurements (WxHxL) in mm 80x125x120
Weight 200g
CPU 314DPM CPU 315DPM CPU 316DPM CPU 317DPM
Program memory 96kByte 192kByte 256kByte 512kByte
Load memory 144kByte 256kByte 512kByte 1MB
Typical processing
time
Bit/Word (ms/k
commands)
0.18 / 0.78 0.18 / 0.78 0.18 / 0.78 0.18 / 0.78
Order No.:
with DP slave
VIPA 314-2DP01 VIPA 315-2DP01 VIPA 316-2DP01 VIPA 317-2DP01
CPU 31xDPM
Module Specific
