Manual VIPA System 300V Chapter 3 Hardware description
HB130E - CPU - Rev. 11/50 3-25
Electrical Data VIPA 314 ... 317
Like CPU 31x additionally:
Ethernet TCP/IP Interface 4port Switch
DVI-slot when expanded to Ethernet
Memory
CompactFlash

Ethernet Interface
Network topology 4port Switch, RJ45 for Twisted-Pair-Ethernet
Medium Twisted Pair
Transfer Rate 10/100MBit
Total length max. 100m per Segment
Measurements and Weight
Measurements (WxHxL) in mm 80x125x120
Weight 200g
CPU 314NET CPU 315NET CPU 316NET CPU 317NET
Program memory 96kByte 192kByte 256kByte 512kByte
Load memory 144kByte 256kByte 512kByte 1MB
Typical processing
time Bit/Word (ms/k
commands)
0.18 / 0.78 0.18 / 0.78 0.18 / 0.78 0.18 / 0.78
Order number
with DP-Slave
VIPA 314-3SL01 VIPA 315-3SL01 VIPA 316-3SL01 VIPA 317-3SL01
Order No. with
DP-Slave/Master
VIPA 314-3DP01 VIPA 315-3DP01 VIPA 316-3DP01 VIPA 317-3DP01
CPU 31xNET
Module Specific
