Every CPU 31x with TCP/IP is delivered with the following addresses:
IP address: 172.16.192.11
Subnet mask: 255.255.255.0
This IP address is only valid for the first configuration. For control purposes
you find this address on a label under the flap and in the added test
protocol.
Note!
Please regard that every IP address must be unique within the network an
CP an PC have to be connected to the same IP circle. To rearrange the IP
circle you can either change the CP IP address by using [Change IP] or the
IP address of your PC by click on "network" with the right mouse button.
Via Properties you will reach a dialog window. Here you may type a new IP
address and subnet mask depending on the operating system.
Before making changes, you should note the recent values in the networks
properties.
For the access on the address 172.16.192.11 via Ethernet, you change the
IP address of the network card of your projecting PC to:
172.16.192.X, where "X" can get all values between 0 and 255 except 11.
For the subnet mask you choose: 255.255.255.0
For your projecting PC is in the same IP circle like the CP, you may access
the CP via the Ethernet.
In the "network" window mark the station to be transfered.
• Activate the online functions via
.
• If there is still an online connection to the CP, set the CP into software
STOP via
an start transfer with .
• As soon as the transfer has finished, reboot the CP via
.
to a)
Transfer directly via
Ethernet
Transfer the
configuration data
with online functions
↓
↓
↓
