Project engineering
The description below refers to modules that are at the same bus together
with the CPU 31x from VIPA.
In order to address the installed peripheral modules individually, specific
addresses in the CPU have to be assigned to them.
The allocation of addresses and the configuration of the installed modules
is a function of the Siemens SIMATIC manager.
The project engineering of the CPU 31x, the Profibus components and
System 300V modules from VIPA happens in the Siemens SIMATIC
manager.
The parameterization of the Ethernet components takes place via the VIPA
parameterization tool WinNCS.
With the help of the VIPA Green Cable you may transfer your project from
the PC into the CPU via the MPI interface.
You may also copy your project with a common MMC reading device to a
MMC and transfer it into the CPU by means of an Overall reset.
To be compatible to the Siemens SIMATIC manager, you have to configure the System
300V CPUs from VIPA as
CPU 315-2DP (6ES7 315-2AF03 V1.2)!
Please regard that the Profibus address 1 is reserved for the system. You
should not use the address 1!
• Start Siemens SIMATIC manager with new project and configure
Siemens CPU 315-2DP (6ES7 315-2AF03 V1.2). The CPUs 31x from
VIPA have to be included into the hardware configurator from Siemens
as
CPU 315-2DP (6ES7 315-2AF03 V1.2).
• The modules are linked-up in the plugged-in sequence starting with
slot 4.
• Via double click on the CPU or the modules you may parameterize
them.
• When deploying a CPU 31xDP with a master system the CPU can be
connected as slave system CPU 31x by means of "configured stations".
A condition is that the slave system was projected before.
• Save and transfer your project.
In the following these points are more near described.
Overview
Profibus address
1 is reserved
Fast introduction
