VIPA System 300V - Chapter 4 Deployment CPU 31 X

Manual VIPA System 300V Chapter 4 Deployment CPU 31x
HB130E - CPU - Rev. 11/50 4-1
Chapter 4 Deployment CPU 31x
This chapter describes the deployment of a CPU 31x together with the
peripheral modules of the System 300V. The description applies to those
modules that have been inserted together with the CPU on one profile rail
and are connected via the backplane bus.
Besides commissioning and start-up behavior you will find here also a
description of the project engineering, parameterization, operating modes
and test functions.
This information also basically applies to the deployment of the CPU 31x
with integrated communication part.
Topic Page
Chapter 4
Deployment CPU 31x......................................................4-1
Fast introduction...................................................................................4-2
Hints for the deployment of the MPI interface.......................................4-4
Installation............................................................................................4-5
Start-up behavior..................................................................................4-6
Addressing...........................................................................................4-7
Project engineering ..............................................................................4-9
Parameter adjustment CPU ............................................................... 4-12
Project transfer................................................................................... 4-13
Operating modes................................................................................4-19
Overall Reset .....................................................................................4-20
Firmware update ................................................................................4-22
VIPA specific diagnostic entries .........................................................4-25
Using test functions for the control and monitoring of variables.......... 4-27
Note!
This information is valid for all the CPUs described in this manual, since the
back panel communication between the CPU and the peripheral modules is
the same for all models of CPU!
Outline
Content
