Chapter 4 Deployment CPU 31x Manual VIPA System 300V
4-2 HB130E - CPU - Rev. 11/50
Fast introduction
The System 300V CPU is instruction compatible to the programming
language STEP
®
7 from Siemens and may be programmed via the
SIMATIC manager from Siemens.
A large function library is delivered in this package.
Note!
For programming of a System 300V CPU from VIPA please use always the
CPU 315-2DP (6ES7 315-2AF03) from Siemens in the hardware catalog.
For the project engineering, a thorough knowledge of the hardware
configurator from Siemens is required!
When using the System 300V as intelligent slave, the configuration works
via the hardware configurator by Siemens by means of "configured
stations" as CPU 31x.
The configuration of the optional integrated Profibus master takes place via
the hardware configurator from Siemens. The project may be saved on the
MMC.
The CP integrated in the CPU 31xNET is projected by WinNCS. The
project engineering may be executed online via Ethernet or offline by
means of a MMC.
The CP supports PU/OP functionality for up to 64 participants and is
accessible by the "PLC" functions via Ethernet.
WinNCS allows you to execute a firmware update online and password
protected or to reboot the CP part independently from the CPU.
The access rights to the CP are restricted by means of IP list that are
transferred at project engineering.
With an invalid CP project engineering, the project at the CP is deleted and
the CP reboots with the default IP address.
Firmware and project engineering are stored at a DOC (DiscOnChip).
CPU, CP and Profibus master use the MultiMediaCard (MMC) as external
storage medium. The MMC is available from VIPA.
With an Overall reset, it is automatically read from MMC.
Compatibility
Connection to
Profibus-DP
Deployment of the
CP part of the
CPU 31xNET
MultiMediaCard
as external
storage medium
