Viper 480XV - Page 17

©
2005 Directed Electronics, Inc. all rights reserved 17
+ 12V FUSED
7.5A /MOTOR
15A
(+) 12V
MOTOR (+)
UNLOCK WIRE
X
CUT
X
X
CUT
X
MOTOR (+)
LOCK WIRE
GREEN/BLACK
LOCK #30 COMMON (OUTPUT)
WHITE/BLACK
LOCK #87A NORMALLY CLOSED
VIOLET/BLACK
LOCK #87 NORMALLY OPEN (INPUT)
VIOLET
UNLOCK #87 NORMALLY OPEN (INPUT)
BLUE/BLACK
UNLOCK #30 COMMON (OUTPUT)
BROWN/BLACK
UNLOCK #87A NORMALLY CLOSED
