Primary Harness (H1) Wire Connection Guide
Primary Harness Wiring Diagram
___
___
___
___
___
___
___
___
___
___
___
___
___
___
___
___
___
___
___
___
Primary Harness Wiring Instructions
This guide describes in detail the connection of each wire. Also included are possible applications
of each wire. This system was designed with the ultimate in flexibility and security in mind. Many
of the wires have more than one possible function. Please read carefully to ensure a thorough under-
standing of this unit.
BLUE/BLACK Unlock 30 (Common)
VIOLET Unlock 87 (Normally Open)
WHITE/BLACK Lock 87A (Normally Closed)
GREEN/BLACK Lock 30 (Common)
VIOLET/BLACK Lock 87 (Normally Open)
RED/WHITE Channel 2 (-) Output
BLACK/WHITE 1 (+) or (-) Interior Light Illumination Input (87)
BLACK/WHITE 2 Interior Light Illumination Output (30)
WHITE 2 Indicator Light Flash Output
WHITE 1 Indicator Light Flash Output
BROWN/BLACK Unlock 87A (Normally Closed)
WHITE/BLUE Channel 3 (-) Output
BROWN (-) Horn Output
N/A Not Used
GREY (-) Bonnet Trigger Input, Zone 6
VIOLET (+) Door Trigger Input, Zone 3
BLUE (-) Boot Trigger Input, Zone 1
GREEN (-) Door Trigger Input, Zone 3
BLACK (-) Chassis Ground Input
ORANGE Ground-When-Armed (-) Output
H1/1
H1/2
H1/3
H1/4
H1/5
H1/6
H1/7
H1/8
H1/9
H1/10
H1/11
H1/12
H1/13
H1/14
H1/15
H1/16
H1/17
H1/18
H1/19
H1/20
