Diagnostics
The system’s microprocessor monitors and reports all active and violated zones when arming and
disarming. LED flashes indicate the active or violated zone; siren chirps indicate system status.
Arm/Disarm Diagnostics
The number of siren chirps will indicate the status of the system when arming and disarming. For
information on which zone is active or has been violated refer to the
Table of Zones
.
System Status Chirps
Table of Zones
Note: The Warn Away
®
response on zones 4 or 7 do not report on the LED.
Zone No. Trigger type Input description
1 Instant H1/4 BLUE wire. Connect to boot pin switch.
2 Instant On-board Ultrasonic sensors.
3 Instant Door switch circuit. H1/3 GREEN or H1/5 VIOLET.
4 Multiplexed Input 1 Inputs shorter than 0.8 seconds will trigger a
Warning Zone response, while inputs longer than
0.8 seconds will instantly trigger the full alarm
sequence.
5 Progressive Ignition input.
6 Bonnet trigger H1/6 GREY
7 Multiplexed input 2 Inputs shorter than 0.8 seconds will trigger a
Warning Zone response, while inputs longer than
0.8 seconds will instantly trigger the full alarm
sequence.
Action Number of Chirps Description
Arm 1 System armed
Arm 1 (3 second delay), 1 System armed with Bypass Notification
Disarm 2 System disarmed
Disarm 4 System disarmed with Tamper Alert
