SSeennssoorr
AAddjjuussttmmeenntt
LLeevveell
BBaarr NNuummbbeerr aanndd IInnddiiccaattiioonn
0 no bars displayed
1
bar 1 flashes
2
bar 1 solid
3
bar 1 solid, bar 2 flashes
4
bar 1-2 solid
5
bar 1-2 solid, bar 3 flashes
6
bar 1-3 solid
7
bar 1-3 solid, bar 4 flashes
8
bar 1-4 solid
9
bar 1-4 solid, bar 5 flashes
10
bar 1-5 solid
11
bar 1-5 solid, bar 6 flashes
12
bar 1-6 solid
13
bar 1-6 solid, bar 7 flashes
14
bar 1-7 solid
15
bar 1-7 solid, bar 8 flashes
16
bar 1-8 solid
17
bar 1-8 solid, bar 9 flashes
18
bar 1-9 solid
19
bar 1-9 solid, bar 10 flashes
20
bar 1-10 solid
