INSTRUCTION FOR USE ENGLISH
9
TECHNICAL PARAMETERS
Parameter Type Units
Model
AS4325B
Solution tank capacity L / Gal 25 L / 6.6 Gal.
Recovery tank capacity L / Gal 25 L / 6.6 Gal.
Machine Length mm/Inches 1020 mm / 40.1 Inches
Machine width with squeegee mm/Inches 570 mm / 22.4 Inches
Machine width without squeegee
mm/Inches 485 mm / 19.1 Inches
Machine Height (without handle)
mm/Inches 647 mm / 25.5 Inches
Machine Height (with vertical
mm/Inches 1182 mm / 46.5 Inches
Working width mm/Inches 432 mm / 17 Inches
Driving wheel diameter mm/Inches 153 mm / 6 nches
Rear wheel diameter mm/Inches 89 mm / 3.5 Inches
Brush/Pad diameter mm/Inches 432 mm / 17 Inches
Brush/Pad pressure (max) Kg/Lbs. 19 Kg / 41.8 Lbs
Solution Flow (max) per setting L / Gal per minute
(0.59/0.69/1.11/1.68) Liters
(0.16/0.18/0.29/0.44) Gallons
Sound pressure level dB (A)
69 ± 3 dB (A)
Sound pressure level in ECO
dB (A)
65 ± 3 dB (A)
Handle Vibration Level (max) m/s
2
< 2.5 m/s
2
Climbing capacity (max) % grade 2%
Vacuum motor power Watt / H.P. 300 W / 0.4 HP
Vacuum capacity mm/In of H
2
O 900 mm / 35.4 In of H
2
O
Vacuum capacity in ECO mode
mm/In of H
2
O 650mm / 25.6 In of H
2
O
Brush motor power Watt / H.P. 400 Watt / 0.54 HP
Brush speed in normal mode RPM 140 RPM
Brush speed in ECO mode RPM 100 RPM
IP protection class IP IP24
Battery Compartment Size
mm/Inches (265 x 350 x 230) mm / 10.4 x 13.8 x 9.1 Inches
Voltage DC 24 V
Batteries (*) Ah 85Ah C20 / 67Ah C5
Battery run time
Hour Up to 4 hours
On-Board Charger (*) Volts/Amps 24V 10A
Productivity (max) m
2
/h 12,000 sq. ft./hr (1115 m
2
/h)
Machine weight with empty tanks
Kg/Lbs. 58 Kg / 128 Lbs.
Gross Vehicle Weight (GVW) Kg/Lbs. 134 Kg / 295 Lbs.
Shipping Weight Kg/Lbs. 137 Kg / 302 Lbs.
Packing dimensions (L x W x H)
mm/Inches
(1130 x 730 x 1040 mm) / (44.5 x28.7 x 41 Inches)
(*): Optional
