INSTRUCTION FOR USE ENGLISH
24
8. Check whether the contact surface of sealing strip (E) has integrity and sealing is enough. If necessary, take
the sealing strip of the tank out of the groove (F) and replace it. Assemble the new sealing strip as shown in
(Figure 17), the joint should be back in the middle area.
9. Close the recovery tank lid (A).
B
C
A
Figure 17
B
A
E
F
D
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options,
according to the machine specific use:
For further information concerning the above-mentioned optional accessories, contact an authorized Retailer.
ACCESSORIES/OPTIONS
See “Parts List” section
1. GEL/AGM batteries
2. Pads of different materials
3. Brush of different materials
4. On-board charger
5. Squeegee blades of different materials
