7
SYSTEM DIAGRAM
SYSTEM DIAGRAM
Sub-assemblies
Standard box contents:
EVO Cam II camera unit
Power supply unit
Plug cord
HDMI cable
USB3 cable
Lens cloth
2mm HEX key
Objective lenses
Remote Keypad
(optional)
EVO Cam II
360° r
otating viewer
(optional)
(see Optical data t
ables)
ECH 005
EVR066
ECX155
PRESET
P2
P1
P3
Exit
